Item 68525 / 68530
Page 21
For Generator technical questions, please call 1-800-444-3353.
For Engine technical questions, please call 1-800-520-0882.
SAFETYOPERATIONMAINTENANCE SETUP
Record Product's Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and
are not available individually as replacement parts.
Part Description Qty
1 Gasket, Cylinder Head 1
2 Cylinder Head Cover 1
3 Gasket, Cylinder Head Cover 1
4 Tube, Breather 1
5 Bolt Sub, Cylinder Head Cover 1
6 Stud 2
7 Stud 2
8 Pin 2
9 Plug, Spark 1
10 Head Sub, Cylinder 1
11 Crankcase Sub. 1
12 Seal, Oil 1
13 Sensor, Engine Oil 1
14 Bearing 1
15 Plug, Rubber 1
16 Protector, Oil 1
17 Bolt 1
18 Flat Washer 2
19 Bolt, Drain Plug 2
20 Clip 1
21 Arm, Governor 1
22 Seal, Oil 1
23 Pin 1
24 Flat Washer 1
25 Bolt 2
26 Cover, Crankcase 1
27 Gasket, Crankcase 1
28 Bearing 1
29 Dipstick Sub, Oil 1
30 Pin 2
31 Bolt 7
32 Bearing 1
33 Gear Assy, Governor 1
34 Seal, Oil 1
35 Crankshaft Assy. 1
36 Shaft Assy, Balancing 1
37 Ring Set, Oil 1
38 Clip, Piston Pin 2
39 Piston 1
40 Pin, Piston 1
41 Rod, Connecting 1
42 Primary Ring 1
43 Secondary Ring 1
44 Camshaft Assy. 1
45 Valve, Exhaust 1
46 Valve, Intake 1
47 Seat, Valve Spring 1
48 Exhaust Valve Retainer 1
49 Rotator, Valve 1
50 Guide, Seal 1
51 Tappet, Valve 2
52 Lifter Sub, Valve 2
53 Plate Sub, Lifter Stopper 1
54 Bolt, Valve Adjusting 2
55 Rocker, Valve 2
56 Valve Adjusting Nut 2
57 Nut, Valve Lock 2
58 Spring, Valve 2
59 Retainer, Valve Spring 1
Part Description Qty
60 Starter Assy, Recoil 1
61 Bolt 3
62 Shroud 1
63 Shroud, Cylinder Body 1
64 Bolt 1
65 Bolt 5
66 Carburetor Assy. 1
67 Gasket, Air Cleaner 2
68 Gasket, Carburetor 1
69 Plate, Carburetor Insulator 1
70 Gasket, Inlet 1
71 Clip 2
72 Sleeve, Breather Tube Fixing 1
73 Control Assy, Choke 1
74 Valve, One Way 1
75 Cleaner, Air 1
76 Nut 2
77 Nut, Flywheel 1
78 Starter Pulley 1
79 Impeller 1
80 Flywheel Sub. 1
81 Bolt 2
82 Coil, Ignition 1
83 Bolt 1
84 Clamp, Charge Coil 1
85 Bolt 2
86 Coil Sub, Charge 1
87 Bolt 2
88 Control Assy, Throttle 1
89 Spring, Throttle Valve Returning 1
90 Rod, Governor 1
91 Spring, Governor 1
92 Support Sub, Governor 1
93 Nut 1
94 Bolt, Governor Support 1
95 Collar 1
96 Motor, Starting 1
97 Bolt 2
98 Relay, Starting 1
99 Bolt 2
100 Mufer Assy. 1
101 Cover, Mufer Inner 1
102
Cushion, Mufer Insulator Rubber
3
103 Bracket,Mufer 1
104 Bolt 4
105 Cover, Mufer Side 1
106 Bolt 7
107 Cover, Mufer Outer 1
108 Gasket, Exhaust Outlet 2
109 Nut 2
110 Pipe, Exhaust 1
111 Bolt 2
112 Tank, Fuel 1
113 Sleeve, Fuel Tank Rubber 4
114 Bush 4
115 Washer 4
116 Bolt 4
117 Cover, Fuel Tank 1
118 Fuel Strainer 1
Part Description Qty
119 Screw 2
120 Leveler Assy, Oil 1
121 Cock Assy, Fuel 1
122 Collar 2
123 Tube, Fuel 1
124 Frame Assy, Engine 1
125 Nut 4
126 Cushion, Engine Frame 2
127 Cushion, Engine Frame Rear 2
128 Nut 4
129 Brace 1
130 Bolt 2
131 Socket Sub, Power Supply 1
132 Socket Sub, Power Supply 2
133 Protector, Overcurrent 2
134 Terminal Sub, Grounding 1
135 Socket Sub. DC 1
136 Switch Sub. 1
137 Socket Sub, Power Supply 1
138 Protector, Overcurrent 1
139 Protector, Overcurrent 1
140 Case, Panel Rear 1
141 Panel Sub, Control 1
142 Motor Assy. 1
143 Bracket, Motor 1
144 Stator Bolt 4
145 Washer 1
146 Rotor Bolt 1
147 Regulator, Voltage 1
148 Bolt 2
149 Brush Sub, Carbon 1
150 Bolt 1
151 Cover, Motor Rear 1
152 Bolt 2
153 Block, Terminal 1
154 Bolt 2
155 Band 2
156 Bolt 2
157 Stator Bolt 2
158 Washer 2
159 Stator Nut 2
160 Bolt 1
161 Stopper, Motor Right Cover 1
162 Shroud, Motor 1
163 Bolt 1
164 Bolt, Cylinder Head 4
165 Valve, One Way 1
166 Clamp 1
167 Hose, Fuel Steam Rubber 1
168 Clamp 1
The following parts are only on
Item 68525 (EPA/CARB version)
169 Bolt 2
170 Collector, Fuel Steam 1
171 Clamp 1
172 Hose, Air Cleaner Rubber 1
173 Clamp 1
Parts List and Diagram
