Predator 68527 - Parts List and Diagram

Item 68527 / 68528
Page 20
For Pump technical questions, please call 1-800-444-3353.
For Engine technical questions, please call 1-800-520-0882.
SAFETY OPERATION MAINTENANCESETUP
Part Description Qty
1 Gasket, Cylinder Head 1
2 Cylinder Head Cover 1
3 Gasket, Cylinder Head Cover 1
4 Tube, Breather 1
5 Bolt, Cylinder Head 4
6 Stud 2
7 Stud 2
8 Pin 2
9 Bolt, Cylinder Head 4
10 Plug, Spark 1
11 Head Subassembly, Cylinder 1
12 Crankcase Subassembly 1
13 Sensor, Engine Oil 1
14 Gear Assy, Governor 1
15 Arm, Governor 1
16 Bolt, Drain Plug 2
17 Washer 2
18 Bearing 1
19 Seal, Oil 1
20 Washer 3
21 Pin 1
22 Bolt 2
23 Cover, Crankcase 1
24 Bearing 1
25 Seal, Oil 1
26 Gasket, Crankcase 1
27 Pin 2
28 Dipstick Subassembly, Oil 1
29 Bolt 6
30 Crankshaft Assy. 1
31 Ring Set, Oil 1
32 Clip, Piston Pin 2
33 Piston 1
34 Pin, Piston 1
35 Rod, Connecting 1
36 Primary Ring 1
37 Secondary Ring 1
38 Camshaft Assy. 1
39 Valve, Exhaust 1
40 Valve, Intake 1
41 Seat, Valve Spring 1
42 Exhaust Valve Retainer 1
43 Rotator Valve 1
Part Description Qty
44 Guide, Seal 1
45 Tappet, Valve 2
46 Lifter, Valve 2
47 Plate Subassembly, Lifter Stopper 1
48 Bolt, Valve Adjusting 2
49 Rocker, Valve 2
50 Valve Adjusting Nut 2
51 Nut, Valve Lock 2
52 Spring, Valve 2
53 Starter Assy, Recoil 1
54 Bolt 3
55 Shroud 1
56 Shroud, Cylinder Body 1
57 Shield,Lower 1
58 Protector, Oil 1
59 Bolt 4
60 Bolt 2
61 Bolt 1
62 Collar 1
63 Bolt 1
64 Carburetor Assy. 1
65 Gasket, Air Cleaner 1
66 Gasket, Carburetor 1
67 Plate, Carburetor Insulator 1
68 Gasket, Carburetor Insulator 1
69 Nut 2
70 Air Filter Assembly 1
71 Nut, Flywheel 1
72 Starter Pulley 1
73 Fan 1
74 Flywheel Subassembly 1
75 Bolt 2
76 Coil, Ignition 1
77 Support Subassembly, Governor 1
78 Nut 1
79 Bolt, Governor Support 1
80 Spring, Governor 1
81 Rod, Governeor 1
82 Spring, Throttle Valve Returning 1
83 Control Assy, Throttle 1
84 Bolt 2
85 Mufer Assy. 1
86 Cover, Mufer Outer 1
Parts List and Diagram
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List
