Predator 72899 - Parts List and Diagram

Page 25
For technical questions, please call 1-888-866-5797.
72899
SAFETYOPERATIONMAINTENANCE SETUP
Part Description Qty
1 Gasket, Crankcase 1
2 Tube, Oil Drain 1
3 Crankcase Subassembly 1
4 Piece, Breath 1
5 Gasket, Breath Groove 1
6 Cover, Crankcase 1
7 Cylinder Head Bolt 4
8 Cylinder Head Cover Gasket 1
9 Guide, Seal 1
10 Spring, Valve 2
11 Clamp, Valve Lock 4
12 Valves Set 1
13 Seat, Valve Spring 2
14 Gasket, Cylinder Head 1
15 Head Subassembly, Cylinder 1
16 Cover Subassembly, Cylinder Head 1
17 Cylinder Head Pin Limit Plate 1
18 Connecting Rod 1
19 Piston 1
20 Piston Pin 1
21 Piston Pin Clip 2
22 Piston Ring Assy 1
23 Crankshaft Assy. 1
24 Nut, Flywheel 1
25 Lifter, Valve 2
26 Tappet, Valve 2
27 Camshaft Assy. 1
28 Rocker Subassembly, Valve 2
29 Rocker Shaft Subassembly 2
30 Dipstick Subassembly, Oil 1
31 Protective Cover 1
32 Carburetor Seal Gasket 1
33 Gasket, Carburetor Insulator 1
34 Plate, Carburetor Insulator 1
35 Carburetor Assy. 1
36 Fuel Strainer 1
37 Air Cleaner Seal Gasket 1
38 Tube, Breather 1
39 Secondary Air Filter 1
40 Gasket, Exhaust Outlet 2
41 Bracket,Muffler 1
42 Muffler Assy. 1
43 Installation Support, Muffler Outer Cover 1
44 Shield, Crankcase Side 1
45 Impeller 1
46 Impeller 1
47 Pulley,Starter 1
48 Seat, Starter Cup 1
49 Starter, Recoil 1
50 Shroud 1
51 Magneto Wiring Clamp 1
52 Plug, Spark 1
53 Case Subassembly, Magneto Rotor 1
54 Stator Subassembly, Magneto 1
55 Trigger Assy. 1
56 Motor Assy,Starting 1
57 Ignition Coil 1
58 Jacket 1
59 Wire, Anode 1
60 Wire, Cathode 1
61 Sensor, Engine Oil 1
62 Bolt M5x10 2
63 Bolt M5x16 2
64 Bolt M6x12 13
65 Bolt M6x16 5
Part Description Qty
66 Bolt M6x20 4
67 Bolt M6x28 4
68 Bolt M8x16 5
69 Bolt M8x20 1
70 Bolt M8x32 6
71 Bolt M6x12 2
72 Bolt M6x35 1
73 Screw M6x60 3
74 Screw Cross Groove Pan 1
75 Bolt M8x34 2
76 Bolt M6x105 2
77 Nut M8 2
78 Nut M6 2
79 Nut M10 1
80 Washer Flat 3
81 Washer Flat 1
82 Pin 4
83 Pin 2
84 Bearing Deep Groove Ball 1
85 Bearing Deep Groove Ball 1
86 Seal, Oil 2
87 Clip 3
88 Clamp 1
89 Tube, Fuel 1
90 Joint, Fuel Tube 1
91 Bolt M6x25 2
92 Hoop 2
93 Tube, Intake 1
94 Air Cleaner 1
95 Screw M5X16 2
96 Left Housing Cover Plate 1
97 Bolt M6x12 15
98 Left Housing 1
99 Rubber Sleeve, Fuel Tank 4
100 Hex Step Bolt M6x20 6
101 Nut M5 15
102 Crosspiece, Back 1
103 Bolt M6x16 5
104 Mounting Plate, Fuel Steam Collector 1
105 Carbon Canister 1
106 Jacket, Rubber 1
107 Rubber Hose, Fuel Steam 1
108 Rubber Hose, Air Cleaner 1
109 Rubber Hose, Fuel Steam 1
110 Jacket 2
111 Pipe Clamp 2
112 Pipe Clamp 4
113 Frame Assy, Engine 1
114 Frame Assy, Engine 1
115 Nut M8 18
116 Self-Tapping Screw 8
117 Handle 2
118 Battery Case 1
119 Battery 1
120 Band 1
121 Plate, Right Bottom 1
122 Invertor 1
123 Jacket 3
124 Bush 3
125 Bolt M6x25 7
126 Grounding 1
127 Flat Washer 1
128 Pan Head Screw 1
129 Seat, Panel 1
130 Bolt M5x16 15
Parts List and Diagram
Parts List
