Predator PH16-71 - LCD Module Removal

1-28 Disassembly Procedures
LCD Module Removal 0
Prerequisite:
Mainboard Removal
1. Unroute the eDP cable from the cable guides as shown in Figure 1-36.
Figure 1-36. LCD Module Removal
2. Flip the notebook. Then remove six (6) screws securing the LCD hinges (Figure 1-37).
Figure 1-37. LCD Module Removal
