13
Eris™ Series E44 and E66 Owner’s Manual
Input Impedance
E44 and E66 10 kΩ
USER CONTROLS
Volume Range
E44 and E66 A-type taper
MF Control
E44 and E66 Variable (-6 to +6 dB)
HF Control
E44 and E66 Variable (-6 to +6 dB)
Low Cut
E44 and E66 Flat, 80 Hz, 100 Hz
Acoustic Space
E44 and E66 Flat, -2 dB, -4 dB
PROTECTION (E44 and E66)
RF interference
Output-current limiting
Over-temperature
Turn-on/off transient
Subsonic filter
External mains fuse
POWER
E44 and E66 100-120V ~50/60 Hz or 220-240V ~50/60 Hz
CABINET
E44 and E66 Vinyl-laminated MDF
PHYSICAL
(Width/Height/Depth)
E44 7” x 7” x 14.3” (180 mm x 180 mm x 365 mm)
E66 8.5” x 9.8” x 18.1” (215 mm x 250 mm x 460 mm)
Weight
E44 11.9 lb (5.4 kg)
E66 23.4 lb (10.6 kg)
