CONTROLS & CONNECTIONS
8
• L/R Assign
• IDSS Control
• Phantom Power Switch
• Phase Reverse Switch
• -20db Pad
• 80 Hz Filter
• Gain Control
Master Channel contains:
• Stereo Output Control
• Headphone Level Control
2.2 PREAMPLIFIER SECTION
L/R Assign button assigns the signal coming through the channel to the stereo Left/Right Mix Bus
output.
Pan control provides constant power panning to the stereo summing bus.
IDSS Control selects the amount of boost or cut applied to the even harmonic series of the signal
being inputted. The effect of manipulating the harmonic distortion is of increasing or decreasing the
apparent “warmth” of the signal. This capability is due to a new transformer that PreSonus is proud to
debut in the M80. Experiment with IDSS and see what type of sounds you can get from your present
microphone selection.
