CONTROLS & CONNECTIONS
12
A pair of XLR connectors are provided for the Left And Right Outputs of the stereo Mix Bus.
Signals are assigned to these outputs using the L/R Assign switches on the individual channels.
2.7 Power Supply
The Power Jack on your M80 Power Supply accepts a standard IEC cord like those found on most
computers and professional recorders. You can be assured of clean power and rugged construction that
will last a long time!
Before powering on your M80 for the first time, be sure to check the position of the power selector.
Make certain that the power voltage level selected for operation of the unit matches that of the country
where the unit will be used. (USA = 115V)
