Digital Audio
ADC Dynamic Range (A-wtd, 48 kHz) 118 dB
DAC Dynamic Range (A-wtd, 48 kHz) 118 dB
FireWire S400, 400 Mb/s
Internal Processing 32-bit, floating point
Sampling Rate 44.1, 48 kHz
A/D/A Bit Depth 24 bits
Reference Level for 0 dBFS +18 dBu
Clock
Jitter <20 ps RMS (20 Hz - 20 kHz)
Jitter Attenuation >60 dB (1 ns in ≈ 1 ps out)
Power
Connector IEC
Input-Voltage Range 90 to 240 VAC (factory-configured for country of destination)
Power Requirements (continuous) 100W
Physical
Length 16 inches (406.4 mm)
Width (chassis only) 15.75 inches (400 mm)
Maximum Height 15.25 inches (133.4 mm)
Weight 15 lbs. (6.8 kg)
