Replacement Parts
Fig. 2: Prestige Jacket Components
Item Part No. Description
1 PSCS01 Display/Control Panel
2 PSCS02 Display Back Panel
3 PSJKT01B Connection Flange Panel
4 PSJKT02B Base Panel
5 PSJKT01F Front Jacket Panel
6 PSJKT01R Rear Jacket Panel
7 PSJKT01S Side Jacket Panel (Left and Right)
8 PSJKT01T Top Jacket Panel - Front
9 PSJKT02T Top Jacket Panel - Rear
10 PSJKT03 Control Cover Panel
11 PSRKIT21 Wall Mounting Bracket with Hardware
