Replacement Parts
Item Part No. Description
1 PSRKIT09 Combustion Chamber Insulation
PSRKIT10 Burner Head with Gasket - Natural
PSRKIT11 Burner Head with Gasket - Propane
3 PSRKIT12 Burner Plate
4 PSRKIT13 Blower with Gasket
5 PGRKIT01 Gas Valve
6 -- Venturi -001
7 PSRKIT14 Ignition Cable
8 PSRKIT15 Igniter with Gasket
9 PSRKIT16 Sight Glass Assembly (Glass, Gasket and Bracket)
10 -- Propane Orifice 0.204" (#52) - Not Shown
11 -- Burner Plate Gasket - Not Shown
1 2 PGRKIT15 Gas Valve Rectifier Plug - Not Shown
2
Fig. 4: Prestige Burner Components
