Installation Instructions
TECHNICAL INFORMATION
l The installation, the adjustments, conversions and maintenance listed in this
part must only be carried out by qualified persons.
l The safety and automatic adjustment devices of the appliance may only be
modified by an authorised Belling service agent.
l The installation of this gas hob must comply with the standards in force.
l This appliance is not connected to a flue for discharge of the combustion
products; therefore, it must be connected in compliance with the above
mentioned installation rules. Particular attention must be paid to the
instructions given below for ventilation and aeration.
L O C A T I O N
The cooker may be located in a kitchen, kitchen/diner or a bed-
s itting room, but not in a room containing a bath or shower. The
hob must not be installed in a bed-sitting room of less than 20 m
3
.
LPG models shall not be installed in a room or internal space below
g r ound level, e.g. in a basement.
PROVISION FOR VENTILATION
The room containing the cooker should have an air supply in
a c c o rdance with BS 5440: Part 2.
The room must have an opening window or equivalent; some ro o m s
m ay also re q u i r e a permanent vent. If the room has a vo l u m e
between 5 and 10 m
3
, it will re q u i r e an air vent of 50 cm
2
e ffe c t i ve
a rea unless it has a door which opens dire c tly to outside. If the
room has a volume of less than 5 m
3
, it will re q u i r e an air vent of
100 cm
2
e f fe c t i ve area (fig. 1). If there are other fuel burning
a p p liances in the same room, BS 5440: Part 2 should be consult e d
to determine air vent re q u i r e m e n t s .
NOTE: the use of a gas cooking appliance re s u l ts in the pro d u c t i o n
of heat and moisture in the room in which it is installed. Alway s
e n s u re that the kitchen is well ve n t ilated; keep natural ve n t il a t i o n
holes open or install a mechanical ve n t i lation device (fig. 2).
In particular, when using the grill or more than one hotplate burner,
open a window if a mechanical ve n t i lation device is not opera t i n g
(fig. 3).
(*) Air inlet - minimum section: 100 cm
2
5
FIG. 1
FIG. 2
FIG. 3
