IMPORTANT
•
The appliance should be installed by a QUALIFIED INSTALLATION
TECHNICIAN.
The appliance must be installed in compliance with regulations in
force.
You need the following housing area to fit your oven correctly.
The double oven is designed to fit into a cabinet of 600 mm width.
The double oven can be built in the kitchen units, but you must ensure that it is properly
ventilated.
In the diagram the appliance is ventilated by means of the space in the top of the kitchen
cabinet.
Lift the appliance into position onto the shelf, taking care NOT to lift it by the door handles.
If you open the oven doors, you will see some screw holes.
The oven should then be secured to the housing by fitting screws into these holes.
Remember the housing should not be free standing but be secured to the wall and/or adja-
cent fittings.
Fig. 6.1
Dimensions
(mm)
Height
Width
Depth
888
595
564
877
560
555 min.
Housing
Oven
• The appliance must be housed in heat
resistant units.
• The walls of the units must be
capable of resisting temperatures
of 75 °C above room temperature.
WARNING
When correctly installed, your product
meets all safety requirements laid
down for this type of product catego-
ry.
However special care should be taken
around the rear or the underneath of
the appliance as these areas are not
designed or intended to be touched
and may contain sharp or rough
edges, that may cause injury.
INSTALLATION
6
