Emergency
Stop Button
Start
Button
Speed
Lever
Bowl
Lift
Lever
Safety
Cage
PM-30
1 Bowl
2 Guard
3 Flat beater
4 Dough hook
5 Wire whip
MIXING INGREDIENTS
Follow the capacity chart in this manual.
Overloading or not following this chart will damage the mixer and void the warranty.
Agitators should always rotate in a clockwise direction around the bowl. If the agitator moves
Counter-clockwise, contact a MVP Group immediately to remedy incorrect wiring.
IMPORTANT: Make sure the speed control lever is on the first (1) speed.
1. Add the appropriate mixing ingredients into the bowl.
2. Lift completely up on the bowl lift lever until the bowl locks into position.
3. Rotate (PM-10, PM-20) or pull down (PM-30) the bowl guard so it is into the closed position.
A clicking sound will be heard.
NOTE: The mixer will not start if the bowl guard is open or the bowl is in the lowered position.
4. Select the appropriate speed setting by lifting or lowering the speed control lever.
