Technical Information 9-3
DOB 1300-1556 PA-1639 Operator's Manual 2020 X3-45 Commuter
DIMENSIONS AND WEIGHTS
DIMENSIONS AND WEIGHTS
X3-45 COMMUTER
Overall length
(including bumpers)
45.5' (13,8m)
Overall width 101.5 (2.57 m)
Overall height 133 7/8" (3.4 m)
Wheelbase
(center of front axle
to center of drive axle)
334.4" (8494 mm)
Floor height from ground 49" (1,24m)
Ground clearance 11 3/32" (282.8 mm)
Step height from ground
NORMAL/KNEELING
Normal: 14" (356 mm)
Kneeling: 9 3/8" (239 mm)
Step height (other steps) 7" (178mm)
Headroom 79 1/2" (1988 mm)
Curb weight 38 500lb. (17486 kg)
Gross Vehicle Weight Rating (G.V.W.R.)
48 000 lb (21770 kg)
Front axle Gross Axle Weight Rating (G.A.W.R.) 16 500 lb (7 500 kg)
Drive axle (G.A.W.R.) 22 500 lb (10206 kg)
Tag axle (G.A.W.R.) 14 000 lb (6 350 kg)
NOTE
Curb weight is given as an indication only and is subject to vary from coach to coach, mostly due to optional
equipment
The actual Gross Vehicle Weight Rating (G.V.W.R.) and the Gross Axle Weight Rating (G.A.W.R.) for front,
drive and tag axles are listed on a certification plate located on the L.H. control panel in driver's section.
