PREVOST X3-45 Commuter 2020 User Manual

Technical Information 9-5
DOB 1300-1556 PA-1639 Operator's Manual 2020 X3-45 Commuter
TURNING RADIUS
FIGURE 1: TURNING RADIUS DIAGRAM
Table below shows the turning radius values.
Values are for low speed (below 20 mph)
maneuvering where the tag axle is unloaded .
Curb to Curb (value A) corresponds to the outer
tire's track on the ground, Wall to Wall (value B)
includes the vehicle's body overhang.
NOTE
Supplied values are theoretical. Factors such as
ground surface, vehicle speed and road
conditions may significantly affect the turning
radius.
Turning Radius
X3
COMMUTER
A (Curb to Curb)
12.80m (42'0")
B (Wall to Wall)
13.94m (45'9")

PREVOST X3-45 Commuter 2020 Specifications

General

Transmission	Allison B500
Category	Buses
Manufacturer	Prevost
Model	X3-45 Commuter
Year	2020
GVWR	54, 000 lbs
Air Conditioning	Yes
Wheelchair Accessible	Yes
Engine	Detroit Diesel DD13
Length	45 ft
Width	102 in
Horsepower	450 hp
