10
Bat swing speeds can be measured in this mode.
(1) Turning on the power
* See “Turning On the Power” on pg. 6
(2) Selecting modes
・ Press and hold the MODE button for approximately 2 seconds to change modes and select
Batting mode .
* Continuously pressing the MODE button will scroll through the four modes in order.
(3) Setting up the device and taking measurements
Use a commercially sold tripod or similar equipment to set up the device as shown in the
illustration below.
* Always check the surrounding area for safety.
Set up the device 5 ft or less from the assumed point of impact.
* Make sure the location where the device is set up is in line with home plate and the pitcher’s
mound.
* Depending on the bat material and construction, the measured distance may be shorter or
measurement may not be possible at all.
* Make sure the device and tripod are set up in a location where contact with them will not be
made.
Measuring (Batting Mode)
5 ft. or less
5 ft. or less
Example of set-up
