18
www.pridemobility.com Celebrity/Rev G/March 2003
IV. SPECIFICATIONS
Model Numbers
Three-wheel: SC4000OBLK, SC4000VBLU, SC4000FGRE, SC4000CRED
Four-wheel: SC4400OBLK, SC4400VBLU, SC4400FGRE, SC4400CRED
Length
50 in. (3 wheel), 51.75 in. (4 wheel)
Width
24 in.
Tires
Type: Pneumatic; Front: 3 in. x 10 in., Rear: 4 in. x 10 in.
Weight Capacity
350 lbs. maximum
Battery Type
Two 12 volt, 32AH, U-1 type, SLA (sealed lead-acid) or two 12 volt, 40AH, AGM or Gel-Cell
Horsepower
1.4 hp (peak)
Charger
Onboard 3-Amp Charger
Speed (max)
Variable up to 5.25 m.p.h.
Maximum Grade
Variable (refer to figures 1and 2)
Range, Maximum (12V 40AH batteries) Up to 20-30 miles
(12V 32AH batteries) Up to 20-25 miles
Turning Radius
3 wheel: 48 in., 4 wheel: 59 in.
Body Colors
Painted: Candy Apple Red, Forest Green, Viper Blue, and Onyx Black
Seating Standard Option Seating Style: Medium-back luxury contoured seat with sliders, mounted on
pneumatic adjustable seat post
Standard Seating Features:
•
User-adjustable seat sliding mechanism
•
Adjustable armrest height, width, and angle
•
Four adjustable seat-back angles
•
Pneumatic height adjustment with shock absorber action
Dimensions: 18 in. width x 16 in. depth (usable) x 18.5 in. height (usable)
Material: Vinyl: Gray, Brown
Fabric: Gray, Gold
Armrests: Upholstered, matching vinyl or fabric with cosmetic edge guards
Adjustable seatpost height from ground: variable between 23 in. to 26.5 in.
Included Features
Full directional lighting package with front “running lights”; deluxe motorcycle-style rearview mirror (can be
installed on left or right side of tiller); lighted touch pad control console; front basket; user adjustable sliding
seat; full “soft-ride” shock absorber-equipped suspension; pneumatic height-adjustable seat post with shock-
absorber action; four position adjustable seat-back angle; adjustable armrest width, height & angle; dual
microprocessor-based motor controller system; modular controller/charger assembly; infinitely adjustable
tiller with auto-leveling console and shock dampening action; standard front & rear integrated bumpers;
easily accessible charger port receptacle, circuit breaker and freewheel lever; standard non-marring, high
density polyurethane bumper(s); battery well accepts 32AH or 40AH batteries; standard battery fixation
straps; status LED
Brakes
Electronic disc, manual freewheel
Rear Wheel Drive
Sealed Transaxle - 24V
Wheels
Black
Tiller Type
Infinitely adjustable with auto-leveling console
Freewheel Mechanism Availability
Lever at lower right portion of rear shroud
Weight of Scooter TOTAL Weight of Celebrity (with two 12V 40AH batteries) = 211.5 lbs. (3 wheel); 227.5 lbs. (4 wheel)
TOTAL Weight of Celebrity (with two 12V 32AH batteries) = 197.5 lbs. (3 wheel); 213.5 lbs. (4 wheel)
Component breakdown:
Front section: 45.5 lbs.(3 wheel), 61.5 lbs. (4 wheel)
Rear section (without batteries or rear shroud): 64.0 lbs.
Rear plastic shroud: 4.0 lbs.
Seat (Med-back with pneumatic seat platform & sliders): 32.5 lbs.
Batteries: (note: two batteries are required per Scooter) 12V, 40AH 32.0 lbs. (each)
12V, 32AH 25.0 lbs. (each)
Basket: 1.5 lbs.
Front-to-Rear Lockup
Dual lock pins & camlock levers
Ground Clearance
3.5 in.
Accessories
Rear basket; cup holder; portable canopy; safety flag; solid foam filled tires; cane/crutch holder; walker
holder; dust cover; weather breaker canopy; oxygen tank holder
