Go-Go Elite Traveller Plus Technical Troubleshooting Guide www.pridemobility.com 5
Diagram 1. Troubleshooting Key
3
2
1
1
5
6
7
8
9
10
4
12
11
1
2
3
4
5
6
7
8
9
10
11
12
BATTERY HARNESSES
SPEED POT
THROTTLE POT
MOTOR INTERFACE HARNESS
BRAKE HARNESS
MOTOR/TRANSAXLE ASSEMBLY
CONTROLLER
POWER INTERFACE HARNESS
FRONT-TO-REAR INTERFACE HARNESS
FRONT-TO-REAR HARNESS
MAIN CIRCUIT BREAKER
CONSOLE
