Pride Mobility Go-Go Ultra X User Manual

30
www.pridemobility.com Go-Go Ultra X
VII. COMFORT ADJUSTMENTS
Figure 15. Seat Height Adjustment
UPPER SEAT POST
LOWER SEAT POST
DETENT PIN
SEAT HEIGHT ADJUSTMENT
The seat can be repositioned to different heights. See
figure 15.
1. Remove the seat and battery pack from your
Travel Scooter.
2. Use the attached ring to pull and remove the detent
pin from the lower seat post.
3. Raise or lower the upper seat post to the desired
seat height.
4. While holding the upper seat post at that height,
align the adjustment holes of the upper and lower
seat post.
5. Fully insert the detent pin.
6. Replace the battery pack and seat.

Pride Mobility Go-Go Ultra X Specifications

General

Brand	Pride Mobility
Model	Go-Go Ultra X
Category	Scooter
Language	English
