www.pridemobility.com Go-Go Ultra
IV. YOUR SCOOTER
BATTERY PACK
The scooter is equipped with an innovative, easy to remove battery pack. A handle on the top of the battery pack
makes it easy to lift the pack off of the scooter with one hand. The battery pack contains two 12 volt, 12 AH
batteries; the charger power lead receptacle; and the main circuit breaker (reset button). See figure 7.
Figure 7. Battery Pack
CHARGER POWER
LEAD RECEPTACLE
MAIN CIRCUIT BREAKER
(RESET BUTTON)
Charger Power Lead Receptacle
The scooters 3-pin off-board charger lead plugs into this receptacle.
Main Circuit Breaker (Reset Button)
When the voltage in your scooters batteries becomes low or the scooter is heavily strained because of excessive
loads or steep inclines, the main circuit breaker may trip to protect the motor and electronics from damage.
n The main circuit breaker reset button pops out when the breaker trips.
n When the breaker trips, the entire electrical system of your scooter shuts down.
n Allow a minute or two for your scooters electronics to rest.
n Push in the reset button to reset the main circuit breaker.
n If the main circuit breaker trips frequently, you may need to charge your batteries more often. You may also
need to have your authorised Pride Provider perform a load test on your scooters batteries.
n If the main circuit breaker trips repeatedly, see your authorised Pride Provider for service.
BATTERY PACK
Figure 7A. Off-Board Battery Charger
PLUGS INTO BATTERY PACK
PLUGS INTO STANDARD
WALL OUTLET
BATTERY PACK HANDLE
OFF-BOARD BATTERY CHARGER
The off-board battery charger, when plugged into the
charger power lead receptacle (located on the battery
pack) and a standard wall outlet, charges the scooters
batteries. See figure 7A.
