Pride Mobility Go-Go Ultra User Manual

28
www.pridemobility.com Go-Go Ultra
DISASSEMBLY
No tools are required to disassemble or assemble your scooter. Always disassemble or assemble your scooter on
a level, dry surface with sufficient room for you to work. Keep in mind that the disassembled sections of a scooter
take up more floor space than the assembled scooter.
VIII. DISASSEMBLY AND ASSEMBLY
You can disassemble the scooter into four pieces: the seat, the front section, the rear section, and the battery
pack. See figure 11.
Figure 11. Disassembled Scooter
BATTERY
PACK
REAR
SECTION
SEAT
FRONT SECTION
WARNING! Before disassembling the scooter, remove the key and place the manual
freewheel lever in the drive (rearward) position.
1. From the unlocked position (see figure 12), lock the front wheel by pushing the tiller lock knob in and turning
it clockwise 90°. See figure 12A.
WARNING! Lifting weight beyond your physical capability may result in personal injury.
Ask for assistance when necessary before disassembling your scooter.
LOCKED
POSITION
Figure 12A. Tiller Lock Knob (Locked)
Figure 12. Tiller Lock Knob (Unlocked)
UNLOCKED
POSITION
