Pride Mobility Go-Go User Manual

19
Go-Go/Rev H/March 04 www.pridemobility.com
V. YOUR GO-GO
BATTERY PACK
The Go-Go is equipped with an innovative, easy to remove battery pack. A handle on the top of the battery pack
makes it easy to lift the pack off of the scooter with one hand. The battery pack contains two 12 volt, 12 AH
batteries; the charger power cord receptacle; and the main circuit breaker (reset button). See figure 7.
Figure 7. Battery Pack
CHARGER POWER
CORD RECEPTACLE
MAIN CIRCUIT
BREAKER (RESET
BUTTON)
Charger Power Cord Receptacle
The scooters 3-pin off-board charger plug plugs into this receptacle.
Main Circuit Breaker (Reset Button)
When the voltage in your scooters batteries becomes low or the scooter is heavily strained because of excessive
loads or steep inclines, the main circuit breaker may trip to protect the motor and electronics from damage.
n The main circuit breaker reset button pops out when the breaker trips.
n When the breaker trips, the entire electrical system of your scooter shuts down.
n Allow a minute or two for your scooters electronics to rest.
n Push in the reset button to reset the main circuit breaker.
n If the main circuit breaker trips frequently, you may need to charge your batteries more often. You may also
need to have your authorized Pride Provider perform a load test on your scooters batteries.
BATTERY PACK
OFF-BOARD BATTERY CHARGER
The off-board battery charger, when plugged into the
charger power cord receptacle (located on the battery
pack) and a standard wall outlet, charges the scooters
batteries. See figure 7A.
Figure 7A. Off-Board Battery Charger

Pride Mobility Go-Go Specifications

General

Maximum Speed	4 mph
Range per Charge	Up to 12.5 miles
Turning Radius	33"
Overall Length	40"
Overall Width	21"
Top Speed	4 mph
Weight Capacity	300 lbs
Number of Wheels	3
Battery Charger	Off-board
Seat Depth	16 inches
Charger Type	Off-board
Drive System	Rear-wheel drive
