III. YOUR POWER CHAIR
JAZZY 1107 SPECIFICATIONS
Suspension: Active Trac
Drive Wheels: 10 in., pneumatic, (10 in., solid are optional)
Caster Wheels: 6 in., solid, rear-mounted
Anti-tip Wheels: 5 in., solid, front-mounted
Maximum Speed: Up to 4.5 mph*
Brakes: Intelligent Braking electronic regenerative, disc park brake
Ground Clearance: 2.5 in.
Turning Radius: 20 in. (without foot riggings)
Overall Size: Length: 38 in. (without foot riggings)
Width: 23.5 in.
Seating Options: Medium-Back Seat (standard)
Limited Recline High-Back Seat (optional)
Full Recline High-Back Seat (optional)
Specialty Seat (optional)
Synergy Seat (optional)
Drivetrain: Two motor, mid-wheel drive
Batteries: Two 12-volt, U-1 batteries
Range: Up to 25 miles*
Battery Charger: 5-amp, off-board (standard)
8-amp off-board (optional)
Electronics: 60-amp Pride FLIGHT Controller
50-amp PG Drives VSI Controller
70-amp PG Drives Remote Plus Controller
Weight Capacity: 300 lbs.
Component Weights: Base: 95 lbs. (right section 39.5 lbs.; left section 39.5 lbs.; center section 16 lbs.)
Medium-Back Seat: 33 lbs.
Batteries: 29 lbs. each (battery boxes 4.5 lbs. each)
*Depending on user weight and terrain.
Electrical Components
The electrical components consist of the controller assembly, the batteries, and the motors. The batteries, motors, and
controller power module are located on the power base assembly. See figures 6 and 7. The controller is located on the
seat assembly. Connectivity between the controller and the motors, the batteries, and the battery charger is provided by
one or more wiring harnesses.
Controller Harness Connector: The controller harness connector is where the controller plugs into the power base.
Each controller uses a different type of harness. If the controller has a power module in the power base, the connector is a
small communications-type connector. If the controller is integrated, then the harness has a large 9-pin connector. Regardless
of which type of controller is used, the harness must be secured to the seat assembly and not allowed to drag on the floor.
