Jazzy 1107 www.pridemobility.com 23
Figure 14. Jazzy 1107 Battery Box Removal and Frame Separation
BATTERY BOX LATCH
(LOCKED)
BATTERY BOX LATCH
(UNLOCKED)
IV. ASSEMBLY/DISASSEMBLY
CENTER SECTION LATCH
