Jazzy EVO Series www.pridemobility.com 15
V. COMFORT ADJUSTMENTS
Armrest Height Adjustment
To change the armrest height:
1. Loosen the setscrews on the armrest. See gure 9.
2. Raise or lower the armrest to the desired height.
3. Tighten the setscrews to secure the armrest.
Controller Position
You can move the controller in toward or out away from the armrest, or change the position of the controller for
either left-hand or right-hand use.
WARNING! Do not place the controller harness so that it can be pinched in the seat frame or the
power base frame.
To extend the controller:
1. Turn o the power to the controller.
2. Flip up the armrest so it is perpendicular to the oor.
3. Loosen the setscrew on the controller bracket. See gure 9.
4. Slide the controller into or out of the armrest to the desired position.
5. Tighten the setscrew to secure the controller.
To change the controller position:
1. Turn o the power to the controller.
2. Unplug the controller harness from the power base.
3. Cut the wire tie(s) that secure the controller harness to the armrest and seat.
4. Flip up the armrests.
5. Loosen the setscrew on the underside of each armrest. See gure 9.
6. Slide the controller out of the armrest.
7. Place the controller into the other armrest.
8. Tighten the setscrew to secure the controller.
9. Route the controller harness along the seat frame and secure with wire ties. See gure 7.
10. Plug the controller into the power base. See gure 3 or 4.
