Pride Mobility Ranger - Appendix I: Specifications; General Scooter Specifications

39
Ranger www.pridemobility.com
APPENDIX I - SPECIFICATIONS
Model Numbers PMV600
Overall Length
2
See figure 19.
Overall Width
2
See figure 19.
Tyres Type: Pneumatic Front; 15 x 33 cm, Rear: 15 x 33 cm (6 x 13 in.)
Wheels Aluminum alloy wheels in Black
Weight Capacity 181 kg, 28 stone 8 lbs. (400 lbs.)
Battery Type
3
(not included) Two 12V, 100 Ah
Horsepower 3.0 hp (peak)
Charger 8 amp off-board charger
Speed (Max)
1
Variable up to 13 km/h (60% reverse)
Maximum Grade See figure 1.
Range
1
Up to 35 km (21.75 miles) per charge with 100 Ah batteries
Turning Radius
2
See figure 19.
Seating Style: High-back with headrest and sliders
Dimensions: 18”W x 16”D
User adjustable seat height from ground: 70.49-80.65 cm (27.75 - 31.75 in.)
User adjustable seat height from deck: See figure 19.
Brakes Electronic regenerative braking and electromechanical disc brake
Rear Wheel Drive 2-24 VDC motors
Weight Total weight with batteries: w/two 12V, 100 Ah batteries: 156.4 kg (345 lbs.)
Total weight without batteries: seat and rear shroud: 97.98 kg (216 lbs.)
Component Breakdown:
Rear Plastic Shroud:1.59 kg (3.5 lbs.)
Seat: 16.78 kg (37 lbs.)
Batteries: 29 kg each (63.5 lbs.)
Ground Clearance
2
See figure 19.
1
Varies with user weight, terrain type, battery amp-hour (Ah), battery charge, battery condition and tyre condition. This
specification can be subject to a variance of (+ or -) 10%.
2
Due to manufacturing tolerances and continual product improvement, this specification can be subject to a variance of (+
or - ) 3 %.
3
AGM or Gel-Cell type required. See IV. “Batteries and Charging.”
NOTE: This product conforms to all applicable ANSI-RESNA testing requirements and ISO 7176 Series
EN12184 standards. All specifications subject to change without notice.
