18
www.pridemobility.com Cyclone/RevB/Apr03
IV. SPECIFICATIONS
Model Numbers Three-wheel: SPSC4000CRED (Candy Apple Red), SPSC4000VBLU (Viper Blue), SPSC4000OBLK (Onyx
Black), SPSC4000FGRE (Forest Green),
Four-wheel: SPSC4400CRED, SPSC4400VBLU, SPSC4400OBLK, SPSC4400FGRE
Length 50 in. (3-wheel), 51.75 in. (4-wheel)
Width 26 in.
Tires Type: Pneumatic; Front: 3 in. x 10 in., Rear: 4 in. x 10 in.
Weight Capacity 300 lbs. Maximum
Battery Type Two 12 volt, 32 AH, U-1 type, SLA (sealed lead-acid) or two 12 volt, 40 AH, AGM or Gell-Cell
Horsepower 2.0 hp (peak)
Charger Onboard 3-amp charger
Speed (max) Variable up to 5.25 mph (8 mph max with Turbo Mode)
Maximum Grade Variable (refer to figures 1 and 2)
Maximum Range (12V 40 AH batteries)
Up to 20-30 miles
(12V 32 AH batteries)
Up to 20-25 miles
Turning Radius 3-wheel: 48 in., 4-wheel: 59 in.
Body Colors Painted: Candy Apple Red, Viper Blue, Forest Green, and Onyx Black
Seating Standard Option Seating Style:
Sport Scooter high back with headrest and sliders, mounted on a
Pneumatically adjustable seat post
Standard Seating Features:
•
Marine grade user-adjustable seat sliding mechanism
•
Adjustable armrest height, width, and angle
•
Four adjustable seatback angles
•
Pneumatic height adjustment with shock absorber action
Dimensions:
19 in. width x 17.5 in. depth (usable) x 26.5 - 29 in. height (usable)
Material:
Gray or Black Vinyl
Armrests:
Match seat cover material
Adjustable seat post height from ground:
variable between 23 in. to 26.5 in.
Included Features Full directional lighting package with front “running lights”; deluxe motorcycle-style rearview mirror (can be
installed on left or right side of tiller); lighted touch pad control console; front basket; user adjustable sliding
seat; full “soft-ride” shock absorber-equipped suspension; pneumatic height-adjustable seat post with shock-
absorber action; four-position adjustable seat-back angle; adjustable armrest width, height & angle; dual
microprocessor-based motor controller system; modular controller/charger assembly; infinitely adjustable
tiller with auto-leveling console and shock dampening action; standard front & rear integrated bumpers;
easily accessible charger port receptacle, circuit breaker and freewheel lever;
standard non-marring, high
density polyurethane bumper(s); battery well accepts 32AH or 40AH batteries; standard battery fixation
straps; diagnostic beep codes; turbo function; speed control technology (SCT); brushless motor/controller
Brakes Electronic disc, manual freewheel
Rear Wheel Drive Sealed Transaxle - 24V
Wheels Aluminum alloy wheels in Black
Tiller Type Infinitely adjustable with auto-leveling console
Freewheel Mechanism Lever at lower right portion of rear shroud
Weight of Scooter TOTAL Weight of Cyclone (with two 12V 40 AH batteries) = 224 lbs. (3 wheel); 243 lbs. (4 wheel)
TOTAL Weight of Cyclone (with two 12V 32 AH batteries) = 209 lbs. (3 wheel); 228 lbs. (4 wheel)
Component breakdown:
Front section: 46.5 lbs.(3-wheel), 62.5 lbs. (4-wheel)
Rear section (without batteries or rear shroud): 66.0 lbs.
Seat (High back with pneumatic seat platform & sliders): 44 lbs.
Batteries (note: two batteries are required per Scooter): 12V, 40 AH 32.0 lbs. (each)
12V, 32 AH 25.0 lbs. (each)
Front-to-Rear Lockup Dual lock pins & camlock levers
Ground Clearance 3.5 in.
Accessories Rear basket; cup holder; safety flag; dust cover; weather breaker canopy; lap belt
