35
Cyclone/RevB/Apr03 www.pridemobility.com
IX. DISASSEMBLY AND ASSEMBLY
Figure 24. Ball Detent Pins With Rings
Figure 25. Separating The Frame Sections
Figure 26. Motor Harness
Figure 22. Battery Removal
Figure 21. Disconnecting The Front-To-Rear Harness
Figure 20. Disconnecting The Battery Harnesses
UNLOCKED POSITION
Figure 23. Locking Cam Levers
