III. YOUR POWER CHAIR
THE JAZZY 1107
The Jazzy has two main assemblies: the seat assembly and the power base assembly. See figure 5. Typically, the seat assembly
includes the armrests, seatback and seat base. The power base assembly includes two motor/brake assemblies, two drive
wheels, two anti-tip wheels, two castor wheels, two battery boxes and wiring harnesses. See figures 5, 6, and 7.
Figure 5. The Jazzy 1107
SEATBACK
ARMRESTS
CONTROLLER
ANTI-TIP WHEELS
DRIVE WHEEL
CASTOR WHEEL
POWER BASE
ASSEMBLY
SEAT ASSEMBLY
JOYSTICK
FOOT RIGGING (FOOT
PLATFORM SHOWN)
SEAT BASE
SEATBACK RELEASE LEVER
