Jazzy 1107 www.pridemobility.com 41
APPENDIX I - SPECIFICATIONS
SPECIFICATIONS
Suspension: Active Trac
Drive Wheels: 25.4 cm (10 in.), pneumatic or solid available
Castor Wheels: 15.25 cm (6 in.), solid, rear-mounted
Anti-tip Wheels: 12.7 cm (5 in.), solid, front-mounted
Maximum Speed:¹ Up to 7.25 km/h (4.5 mph)
Range:¹ Up to 17 km (11 miles)
Brakes: “Intelligent Braking” electronic regenerative, disc park brake
Ground Clearance:² See figure 30.
Turning Radius:² See figure 30.
Overall Size:² Length: See figure 30.
Width: See figure 30.
Drivetrain: Two motor, mid-wheel drive
Batteries:³ Two 12-volt, U-1 batteries
Battery Charger: 5-amp, off-board
Weight Capacity: 136 kg (21 stone/300 lbs.)
Component Weights: Base: 44.45 kg (98 lbs.)
Right Section: 18.37 kg (40.5 lbs.)
Left Section: 18.37 kg (40.5 lbs.)
Centre Section: 7.7 kg (17 lbs.)
Medium-Back Seat: 16.78 kg (37 lbs.) average weight with armrests and universal mounting system
Batteries: 13.15 kg ( 29 lbs.) each
Battery Boxes: 2.04 kg (4.5 lbs.) each
¹ Varies with base model, user weight, terrain type, battery amp hour rating (Ah), battery charge, battery condition,
motors, controller type, tyre type and tyre condition.
² Due to manufacturing tolerances and continued product improvement, this specification can be subject to variance of
(+ or – ) 3%.
³ AGM or Gel-Cell type required. See VI. “Batteries and Charging.”
NOTE: All specifications subject to change without notice.
