Jazzy 1107 www.pridemobility.com 7
II. SAFETY
Do not connect an extension lead to the AC/DC converter or the battery charger.
Corrosive chemicals contained in battery.
Explosive conditions exist!
Use only AGM or Gel-Cell batteries to reduce the risk of leakage or explosive conditions.
Do not use batteries with different amp-hour (Ah) capacities. Do not mix old and new
batteries. Always replace both batteries at the same time.
EMI-RFI - This product has been tested and passed at an immunity level of 20 V/m.
Battery Set Configuration:
++
++
+ = Positive (Red) Terminal Post
- = Negative (Black) Terminal Post
Connect Red wire to Red Positive (+) Terminal Post
Connect Black wire to Black Negative (–) Terminal Post
