Sonic I. Frame Assembly — Rear
A1 — E1
A1
*A2
*A3
A4
A5
A6
A7
A8
A9
B1 — B4
B1
B2
B3
B4
C1 — C3
C1
C2
C3
D1 — D4
D1
D2
D3
D4
*E1
F1 — F3
F1
F2
F3
REF #
FRMASMB3904
DWR9905E013
DWR9930B016
SCRSETS1057
DWR9905B022
SCRPPH1113
NUTNYLK1020
SCRSHCS1065
NUTNJAM1020
DWR9905B034
WHLASMB1435
WHLATIP1000
SCRHHCS1061
NUTNYLK1045
WASMETR1026
FRMASMB3905
SCRSHCS1015
REFRED1004
DWR9905E005
HDWASMB1026
DWR9998A005
SCRSHCS1066
WASSTND1091
NUTNYLK1011
DRVASMB1425
FRMASMB4082
DWR5000A043
DWR9905C010
PINCOTD1006
PART #
FRAME,ASSY,REAR,SONIC
FRAME,WELDMENT,REAR, SONIC,E-9905-013
FREEWHEEL,HANDLE,YELLOW,SUNDANCER 2001,B-9930-016
SCREW, SET,BLACK,M4-.7 X 12MM
FRAME,MECHANISM,HOOK LOCK UP, SC50, SONIC,B-9905-022
SCREW, PPH,M4 X .7T X 13MM
NUT,NYLOCK,ZINC,M4-.7
SCREW, SHCS,BLACK ZINC,M8-1.25 X 25MM
NUT,NYLOCK JAM,BLACK ZINC,M8-1.25
LATCH,RETAINER,CATCH, SC50/3000,B-9905-034
WHEEL,ASSY,ANTI-TIP,SONIC
WHEEL,ANTI-TIP,LEGEND/CELEBRITY
SCREW, HHCS,M6-1.0 X 45MM,G2
NUT,NYLOCK,ZINC,M6-1.0
WASHER, FLAT,6MM ID X 13MM OD X 1MM TH
BUMPER,ASSY,REAR,SONIC
SCREW,SHCS,BLACK ZINC,M6-1.0 X 30MM,GRADE 12.9
REFLECTOR,RED,1",CCL
BUMPER,MOLDED,REAR, SONIC,E-9905-005
TRANSAXLE,ASSY,HARDWARE,MOUNTING, SONIC
BRACKET,AXLE MOUNT,BLACK,POWDER COAT,REVO,A-9998-005
SCREW, SHCS,BLACK ZINC,M8-1.25X40MM
WASHER, FLAT,M8
NUT,NYLOCK,BLACK ZINC,M8-1.25
MOTOR,ASSY,MAIN TRANSAXLE/MOTOR/BRAKE,CCL, (PM802-T02)
SEAT POST,ASSY,UPPER,2 HOLE, SC50
SEAT POST,BUSHING,1.000" ID X 1.310" OD X 2.112" TH X 2.00" FOD X 0.312"FTH,UPPER,A-
5000-043
SEAT POST,UPPER, WELDMENT,2 HOLE,CHROME,SONIC,C-9905-010
PIN,COTTERLESS DETENT W/RING,.375" DIA X 2.00" GRIP LENGTH,B-1005-169
DESCRIPTION
1
1
1
1
1
3
3
1
1
1
2
1
1
1
2
1
4
2
1
1
2
4
8
4
1
1
1
1
1
QTY
Refer to SECTION II. — Drive Assembly for the illustration.
Refer to SECTION II. — Drive Assembly for the illustration.
Refer to SECTION II. — Drive Assembly for the illustration and the parts list.
Notes :
*A2
*A3
*E1
