Jazzy 1100Sonic
A. Electrical System Diagram
HARUSHD2337
DWR9905H001
HARUSHD2329
HARUSHD2328
DWR9905H009
DWR9998H014
DWR9905H020
DWR9905H007
DWR9915H010 DWR9915H010
DWR9905H005
DWR9905H002
DWR9905H003
DWR9905H011
DWR9905H010
ELEASMB2867 -
ELECTRONIC CONSOLE
CTLDC1283 -
PCB BOARD
CTLDC1248 -
CONTROLLER
DRVASMB1425 -
TRANSAXLE/MOTOR
TO BATTERIES
HORN
CIRCUIT
BREAKER
HORN
SWITCH
VOLTMETER
KEY
JACK
SPD POTSTATUS
5A FUSE
AMMETER
ELEASMB2663
THROTTLE POT
TO OFF-BOARD
CHARGER
