Pride Sonic - Vehicle Transport and Mounting Safety

Jazzy 1100
Rev. S/072706 www.pridemobility.com Page 13
Sonic I. Frame Assembly — Seat
A1 — E1
A1 — B3
A1
A2
*A3
*A4
B1 — B3
B1
B2
B3
C1 — D13
*C1 — C11
*C1 — C11
C1
C2
C3
C4
C5
C6
C7
C8
C9
C10
C11
D1 — D13
D1
D2
D3
D4
D5
D6
D7
D8
D9
D10
D11
D12
D13
*E1
REF #
SETASMB5273
SETASMB5164
SETBACK2248
SETBASE2544
FOMINDV1049
FOMINDV1048
PLSASMB1900
DWR1010E420
DWR1010E419
NUTNYLK1012
FRMASMB7927
FRMASMB7929
FRMASMB7928
DWR9998D026
ARM5543C000
DWR9995D015
SCRHHCS1302
NUTNYLK1012
WASSTND1053
SCRPRH1020
WASSTND1102
WASNYLN1083
SCRSHCS1141
NUTJAM1010
FRMASMB4063
SCRHHCS1287
DWR1030B028
WASMETR1055
DWR1000B152
SCRSHCS1111
NUTNYLK1019
DWR9998C016
PROHDLC1007
SPGRAW1010
SPCNYLN1058
DWR9998E022
PINCOTD1000
WASMETR1002
PINCLEV1005
PART #
SEAT,ASSY,MOLDED
PLASTIC,BLACK/GRAY(CHARCOAL),VINYL/FABRIC,18"W,16"D,14"H,LIMITED DUMP,VSCT
SEAT,ASSY,MOLDED PLASTIC,BLACK/GRAY(CHARCOAL),VINYL/FABRIC,18"W,16"D
SEAT BACK,COVER,BLACK/GRAY (CHARCOAL),VINYL/FABRIC,18"W,VSCT
SEAT BASE,COVER,BLACK/GRAY (CHARCOAL),VINYL/FABRIC,18"W,16"D,VSCT
CUSHION,FOAM BACK,18"W
CUSHION,FOAM BASE,18"W,16"D
PLASTIC,ASSY,18"W,16"D,MOLDED,SEAT BACK/SEAT BASE,VSCT
SEAT BACK,MOLDED,BLACK,PLASTIC,17"W,E-1010-420
SEAT BASE,MOLDED,BLACK,PLASTIC,17"W,16"D,E-1010-419
NUT, NYLOCK,ZINC,M8-1.25
SEAT FRAME,ASSY,MOLDED PLASTIC,LIMITED DUMP,STANDARD SEAT PARTS,VSCT
ARMREST,ASSY,BLACK,RIGHT,MOLDED PLASTIC SEAT,VISCOUNT
ARMREST,ASSY,BLACK,LEFT,MOLDED PLASTIC SEAT,VISCOUNT
ARMREST,WELDMENT,UPRIGHT TUBE W/SLOT,W/REINFORCEMENT BLOCK,D-9998-026
ARMREST,WELDMENT,SCOOTER,C-5500-043
ARMREST,LONG,PAD,BLACK,VISCOUNT,D-9995-015
SCREW, HHCS,BLACK ZINC,M8-1.25 X 45 MM,GRADE 8.8
NUT, NYLOCK,ZINC,M8-1.25
WASHER,FLAT,6MM ID X 13MM OD X 1MM TH
SCREW, PRH,M6 X 10MM X 1.0T,G2
WASHER, FLAT,BLACK,ZINC,M8
WASHER,NYLON,M8 ID X 20 OD X 1.5 THK
SCREW, SHCS,BLACK ZINC,5/16-18 X 1 3/4,GRADE 8
NUT,JAM,BLACK ZINC,5/16-18
SEAT FRAME,ASSY,PLATFORM,MOLDED PLASTIC SEAT
SCREW,HHCS,BLACK ZINC,M8-1.25 X 35MM,GRADE 10.9
BRACKET,SEAT PLATE LEVELING,B-1030-028
WASHER, FLAT,BLACK ZINC,8.2MM ID X 16MM OD X 1.0 MM TH,(MTS: 53108008)
HANDLE,LOCK KNOB,B-1000-152
SCREW, SHCS,BLACK ZINC,M6-1.0 X 40MM,GRADE 12.9
NUT,NYLOCK,BLACK ZINC,M6-1.0
LEVER,SEAT RELEASE,ZINC PLATED,REVO,C-9998-016
HANDLE,COVER,SEAT LOCK, SC150
SPRING, RAW,LEVER LOCKING SC150
SPACER, NYLON,13MM OD X 6.5MM ID X 1.0MM TH
SEAT BASE,WELDMENT,5°,REAR PITCH,REVO,E-9998-022
PIN,COTTERLESS DETENT W/RING,.250" DIA X 1.50" GRIP LENGTH,B-1005-168
WASHER, FLAT,M6 X 1MM THICK
CLEVIS PIN,ZINC PLATED,3/8" X 2"
DESCRIPTION
1
1
1
1
1
1
1
1
1
12
1
1
1
1
1
1
1
1
2
2
2
2
1
1
1
4
1
4
2
1
1
1
1
1
2
1
2
1
1
QTY
Not shown.
Not shown.
Both assemblies contain identical parts. There are left and right sides for assembly purposes.
Not shown.
Notes :
*A3
*A4
*C1 — C11
*E1
