Pride Sonic - III. Product Specifications; Scooter Dimensions and Tyre Sizes

Jazzy 1100
Rev. S/072706 www.pridemobility.com Page 15
Sonic I. Frame Assembly — Basket
A1 — A4
A1
A2
A3
*A4
REF #
FRMASMB4051
DWR9998E018
DWR9905C017
SCRSHCS1192
HDWINDV1024
PART #
BASKET,ASSY,12" X 8.50",FRONT, SONIC
BASKET,12" X 8.50",TILLER, OVAL,E-9998-018
BASKET, BRACKET,COMPLETE, FRONT, SONIC
SCREW,SHCS,BLACK ZINC,M6-1.0 X 20MM,GRADE 12.9
ALLEN KEY,5MM
DESCRIPTION
1
1
1
4
1
QTY
Not shown.
Notes :
*A4
