Rev. S/072706 www.pridemobility.com Page 19
Sonic III. Electronics Assembly — Console
A1
B1 — B3
B1
B2
B3
C1 — C11
C1
C2
C3
C4
C5
C6
C7
C8
C9
C10
C11
D1
E1 — E2
E1
E2
REF #
SHDASMB3274
SHDASMB3275
SHDRAWM2165
SCRPPH1110
SCRPPH1021
ELEASMB2867
CTLDC1283
HARUSHD2337
DWR9998H014
SCRPPH1096
HARUSHD2328
DWR9905H001
HARUSHD2329
DWR9905H009
DWR9905B029
DWR9905B035
DWR9905H020
ELEASMB2663
FRMASMB2821
DWR9998B017
SCRSETS1007
PART #
SHROUD,ASSY,CONSOLE TOP,BLACK TEXTURED,SONIC
SHROUD,ASSY,CONSOLE BOTTOM,BLACK TEXTURED,SONIC
SHROUD, REAR CONSOLE,RAW,SC50, SONIC
SCREW,PPH,BLACK ZINC,M3.5 X .35 X 13MM
SCREW,PPH,BLACK ZINC,M3-.5 X 10MM
ELECTRONIC,ASSY,CONSOLE,SC50, SONIC
ELECTRONIC,PCB BOARD,H-9955-015
ELECTRONIC,HARNESS,MOMENTART SWITCH,6",2 PIN,MOLEX CONNECTOR,H-9998-011
ELECTRONIC,HARNESS, HORN,REVO 2 PIN
SCREW, PPH,M2 X 5MM
ELECTRONIC,HARNESS,PHONO JACK,6",2 PIN,MOLEX CONNECTOR,H-9998-002
ELECTRONIC,HARNESS, STATUS LED,GREEN,SONIC
ELECTRONIC,HARNESS,VOLT METER,6",2 PIN,MOLEX CONNECTOR,H-9998-003
ELECTRONIC,SPEED POT W/HARNESS,100K,SPLIT SHAFT, KNURLED, SONIC
KNOB,GRAY,PLASTIC,SPEED POT,B-9905-029
ELECTRONIC,VOLTMETER,RETAINER, SONIC, SC50,B-9905-035
ELECTRONIC,HARNESS, TILLER INTERMEDIATE,SC50/60,H-9905-020
ELECTRONIC,ASSY,THROTTLE POT,REVO
STANDARD PARTS,ASSY,LEVER,THROTTLE CONTROL
WIG WAG,REVO,B-9998-017
SCREW, SET,M4-.7 X 6MM
DESCRIPTION
1
1
1
4
2
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
2
QTY
Notes :
Raw shrouds are not available individually. The assembly must be purchased.
