Rev. S/072706 www.pridemobility.com Page 23
Sonic IV. Shroud Assembly — Front
A1 — A6
A1
A2
A3
A4
A5
A6
B1 — B5
B1
B2
B3
B4
B5
C1 — C6
C1
C2
C3
C4
C5
*C6
D1 — D3
D1
D2
D3
REF #
ELEASMB2949
DWR9905D024
DWR9905H011
DWR9905B030
ELEMETR1003
SCRPFH1042
NUTNYLK1054
ELEASMB2915
ELECBRK1005
INDPART2148
ELEFUSE1013
DWR1000A199
DWR9905C011
HARASMB1042
DWR9905H003
BRKINDV1081
SCRPPH1075
NUTNYLK1054
DWR9905H005
DWR9905H007
ELEASMB2911
INDPART2227
DWR9915H010
BATLIQ1013
PART #
ELECTRONIC,ASSY,PANEL,OFFBOARD CHARGER, SONIC
ELECTRONIC,MODULE,AC, OFFBOARD, PLASTIC, TEXTURED, BLACK, SONIC,D-9905-024
ELECTRONIC,HARNESS, OFFBOARD CHARGER PORT XLR CONNECTOR,SONIC
COVER,RUBBER, OFFBOARD CHARGER XLR CONNECTOR,B-9905-030
ELECTRONIC,AMMETER,0-6
SCREW, PFH,BLACK,M3.5-.6 X 10MM
NUT, NYLOCK,ZINC,M3.5 X .6T
ELECTRONIC,ASSY,PANEL,CIRCUIT BREAKER/FUSE, SONIC
ELECTRONIC,CIRCUIT BREAKER,30 AMP
COVER,12 X 1.25T,BREAKER BUTTON, W/NUT
ELECTRONIC,FUSE,5 AMP,AUTOMOTIVE TYPE
ELECTRONIC,FUSE,CLIP, PRESS FIT, ATO/SPADE TYPE FUSE,A-1000-199
ELECTRONIC,PANEL,CIRCUIT BREAKER/FUSE, PLASTIC, SONIC,C-9905-011
ELECTRONIC,HARNESS,FRONT SHROUD, ELECTRONICS, SONIC
ELECTRONIC,HARNESS, CHARGER/AMMETER/FUSE,BATTERY BOX, SONIC
BRACKET,MOUNT, 2 PIN ANDERSON CONNECTOR
SCREW, PPH,ZINC,M3.5 X .6T X 10MM
NUT, NYLOCK,ZINC,M3.5 X .6T
ELECTRONIC,HARNESS, MOTOR,BATTERY BOX, SONIC
ELECTRONIC,HARNESS, BATTERY,SONIC
BATTERY,ASSY,12 AMP,W/NYLON CASE, SC50, SONIC
BATTERY,CASE,BLACK,NYLON, W/ZIPPER, SC50, SONIC
ELECTRONIC,HARNESS, BATTERY DISCONNECT,W/FUSELINK, SC51,H-9915-010
BATTERY,12 AMP,SCOOTER
DESCRIPTION
1
1
1
1
1
2
2
1
1
1
1
2
1
1
1
2
4
4
1
1
1
1
2
2
QTY
Item is a quantity of one but is being illustrated as four separate parts for assembly purposes only.
Notes :
*C6
