Sonic IV. Shroud Assembly — Rear
A1a — A3
A1b — A3
*A1c — A3
*A1d — A3
A2
A3
REF #
SHDASMB3368
SHDASMB3369
SHDASMB3370
SHDASMB3915
SCRHHCS1061
WASSTND1080
PART #
SHROUD,ASSY,REAR BODY,SONIC RED,SC50 INTERNATIONAL
SHROUD,ASSY,REAR BODY,SONIC BLUE,SC50 INTERNATIONAL
SHROUD,ASSY,REAR BODY,SONIC YELLOW,SC50 INTERNATIONAL
SHROUD,ASSY,REAR,ONYX BLACK,SC50INT
SCREW, HHCS,M6-1.0 X 45MM,G2
WASHER, FLAT,M6,STANDARD
DESCRIPTION
1
1
1
1
2
2
QTY
This color option has been discontinued.
Black color shroud is available only for French models.
Notes :
*A1c — A3
*A1d — A3
Top-level shroud assemblies contain illustrated shrouds designated with corresponding lower-case extensions. Shrouds are not available
individually. The assembly must be purchased. Parts without lower-case extensions will be included in all top-level assemblies.
