Sonic I. Frame Assembly — Tiller
A1 — A7
A1
A2
A3
A4
A5
A6
A7
B1 — B8
B1
B2
B3
B4
B5
B6
B7
B8
REF #
FRMASMB3745
DWR9905E030
DWR9905H010
DWR1020H001
DWR9905C015
PROHDLC1042
SCRSHCS1069
NUTNYLK1019
FRMASMB3749
DWR9905C003
SCRSHCS1111
NUTNYLK1019
DWR9905C004
SPGRAW1004
DWR9998A016
SCRHHCS1364
DWR9998B010
PART #
TILLER,ASSY,SC50, SONIC, VERSION 2
TILLER,WELDMENT,SC50, SONIC, VERSION 2,E-9905-030
ELECTRONIC,HARNESS,TILLER, FRONT TO REAR,SONIC,H-9550-010
TILLER,BOOT,RUBBER, FRONT TO REAR,H-1020-001
GRIP,5.25"L,HAND,BLACK,FOAM,C-9905-015
HAND GRIP,RUBBER,TRANSPORTATION, SC50
SCREW, SHCS,BZ,M6-1.0 X 35 MM
NUT,NYLOCK,BLACK ZINC,M6-1.0
TILLER,ASSY,PIVOT, UPPER AND LOWER,SC50 SONIC
TILLER,KNUCKLE,ADJUST, BOTTOM, SONIC,C-9905-003
SCREW,SHCS,BLACK ZINC,M6-1.0 X 40MM,GRADE 12.9
NUT,NYLOCK,BLACK ZINC,M6-1.0
TILLER,KNUCKLE,ADJUST,TOP,C-9905-004
SPRING,MUSIC WIRE,3/8" X 1 1/2",TILLER,REVO,13.72MM OD X 25.4MM FREE LENGTH,A-
9998-023
SPACER, NYLON,11MM ID X 20MM OD X 1.5MM THK
SCREW,HHCS,BLACK ZINC,M10-1.5 X 60MM,GRADE 8.8
TILLER,KNOB,ADJUSTMENT, REVO,B-9998-010
DESCRIPTION
1
1
1
1
2
1
2
2
1
1
2
2
1
1
1
1
1
QTY
