Pride Sonic - Cornering Safety and Braking Systems

Jazzy 1100
Rev. S/072706 www.pridemobility.com Page 9
Sonic I. Frame Assembly — Fork
A1 — B6
A1
A2
A3
A4
A5
A6
A7
A8
B1 — B6
B1
B2
B3
B4
B5
B6
REF #
FRMASMB3746
DWR9905D006
DWR9905D005
DWR9905D004
SCRPPH1128
DWR9905A011
SCRHHCS1146
DWR9998A008
NUTNYLK1011
HDWASMB1000
WASLOCK1021
INDPART1820
INDPART1804
INDPART1821
INDPART1803
INDPART1819
PART #
FORK,ASSY,SONIC
FORK,WELDMENT,SONIC,D-9905-006
PLASTIC,FENDER,MAIN,SONIC
FRAME,FENDER,PLASTIC, SIDE, SONIC,D-9905-004
SCREW, PPH,BLACK,M3.5-.6 X 10MM
DAMPER,BLACK,RUBBER,MOLDED, SONIC
SCREW,HHCS,BLACK ZINC,M8-1.25 X 95MM,GRADE 10.9
SPACER,0.43 OD X 0.34 ID,1.25MM THK,BEARING,FRONT TIRE,A-9998-008
NUT,NYLOCK,BLACK ZINC,M8-1.25
KIT,BEARING/RACE,KEMCO
WASHER, LOCK,1 ",FRONT FORK,B-1020-037
HEAD CUP, UPPER,CHROME,B-1020-036
CONE HEAD, UPPER,CHROME,C-1020-029
RETAINER,BALL
CONE HEAD,LOWER,CHROME,B-1020-034
HEAD CUP, LOWER,CHROME,B-1020-035
DESCRIPTION
1
1
1
2
4
2
1
2
1
1
2
1
1
2
1
1
QTY
