III. BATTERIES AND CHARGING
Figure 14. Battery Terminal Hardware Figure 15. Battery Wiring Diagram
IDENTIFICATION KEY
1. MAIN CIRCUIT BREAKER
2. BATTERY TERMINALS UNDER BOOTS
3. BATTERY TIE-DOWN STRAP
Figure 13. Battery Removal/Installation Terminals and Connections
