4B
EvoLution Series
Specifications Model EVO 200-4 for EL34 / KT88
Power UL 44 / 45 Watts per channel Stereo
88 / 90 Watts Mono
Frequency Response 10 Hz – 65 kHz +/- 1 dB
10 Hz – 95 kHz +/- 3 dB
THD with AABB < 0.1% @ 1W; less than 2% at rated power Stereo
< 0.17% @ 1W; less than 2% at rated power Mono
S/N Ratio 92 dB Stereo / 93 dB Mono
Input Impedance 100 kOhm
Input Sensitivity 870 / 880 mV (for rated power at maximum volume setting)
Maximum Gain 26.5 dB / 29 dB (EL34 / KT88)
Power Consumption 280 Watts
Weight Net weight: 50.6 lbs / 23 kg
Shipping Weight: 61.6 lbs / 28 kg
Dimensions 15.9" x 14.4" x 8.1" / 405 mm x 365 mm x 205 mm (L x W x H)
Shipping Dimensions 22.7" x 18.4" x 12.4" / 577 mm x 468 mm x 315 mm (L x W x H)
Inputs 1 pair Stereo RCA, 1 piece Mono RCA
Outputs 4, 8 & 16 Ohm / 2, 4 & 8 Ohm Speaker Taps
Damping Coefficient 4 KD (1 kHz)
All PrimaLuna products come with PrimaLuna Silver Label tubes which are pre-selected by us following
our simple 60 out of 100 rule (PTS™ - Premium Tube Selection) and as such, are already “special” when
compared to other standard tubes on the market.
