4C
EvoLution Series
Specifications Model EVO 300-4 for EL34 / KT88
Power UL 44 / 43 Watts Stereo per channel; 85 / 84 Watts Mono
Power TR 22 / 25 Watts Stereo per channel; 45 / 50 Watts Mono
Frequency Response 10 Hz – 70 kHz +/- 1 dB
8 Hz – 75 kHz +/- 3 dB
THD with AABB < 0.1% @ 1W; less than 2% at rated power / < 0.17% @ 1W
S/N Ratio 91 dB (105 dB A Weighted)
Input Impedance 100 kOhm
Input Sensitivity 870 / 880 mV for rated power at max volume setting
Maximum Gain 26 dB / 29 dB
Power Consumption 300 Watts
Weight Net weight: 66 lbs / 30 kg
Shipping Weight: 77 lbs / 35 kg
Dimensions 15.9" x 15.2" x 8.1" / 405 mm x 385 mm x 205 mm (L x W x H)
Shipping Dimensions 22.7" x 18.4" x 12.4" / 577 mm x 468 mm x 315 mm (L x W x H)
Inputs 1 pair Stereo RCA & XLR, 1 piece Mono RCA & XLR
Outputs 4, 8 & 16 Ohm / 2, 4 & 8 Speaker Taps
Tube Complement 4 x EL34, 6 x 12AU7
Damping Coefficient 4 KD (1 kHz)
All PrimaLuna products come with PrimaLuna Silver Label tubes which are pre-selected by us following
our simple 60 out of 100 rule (PTS™ - Premium Tube Selection) and as such, are already “special” when
compared to other standard tubes on the market.
