Connecting the I20 Integrated Amplifier
This chapter explains how to connect the I20 to the other components in your
system, using the connections on the back panel.
]D Audio inputs.
]E Tape outputs.
]F Preamplifier outputs.
TAPE
OUT
RIGHT SPEAKER
+ –
PRE
OUTCD TUNER LINE 1 LINE 2
GROUND
LEFT SPEAKER
– +
]D ]G]E ]F
]C]A ]B
]A Right loudspeaker outputs.
]B Ground terminal.
]C Left loudspeaker outputs
BACK PANEL CONNECTIONS
]G Mains power input and fuse.
