Section 2 Introduction
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Serial plate location
When calling or writing about your product, be sure to
mention model and serial numbers. Model and serial
numbers are located on serial plate as shown.
Parts ordering
information
If replacement parts are required, contact the source
from whom you purchased the unit or contact Alliance
Laundry Systems at (920) 748-3950 for the name and
address of the nearest authorized parts distributor. For
technical assistance, call (920) 748-3121.
Wiring diagram
The wiring diagram is located inside the contactor or
junction box.
