Princeton Instruments PIXIS System - Table 5. Typical Deepest Operating Temperature

Appendix A Basic Specifications 95
95
USB 2.0 (USB B Female): Data link to computer via USB cable inserted at this
connector. Cable length of 5 meters is standard. Other lengths may be available.
Contact Customer Support for more information. USB A/B cable supplied with
system.
Power (DIN): 12 VDC (6.6A max) input from power supply.
Pin 3, 5: 12 VDC
Pin 1, 2, 4: Return
Shell: Ground
Fan: (Air-cooled systems only) 24 CFM fan capacity at full power.
Coolant Ports: (Liquid-cooled systems only) Two interchangeable 1/4" CPC valved
quick disconnect fittings for connection to the CoolCUBE
II
circulator hoses.
Deepest Operating Temperature:
CCD Size
Typical
512x512
-70°C
1024x1024
-70°C
2048x2048
-65°C
1340x100
-80°C
1340x400
-75°C
Table 5. Typical Deepest Operating Temperature
Temperature Stability: ±0.05°C; closed-loop stabilized-temperature control
Power Input: Small Format PIXIS: 100-240 V
AC
; 47 to 63 Hz, 1.9A. DC power to
camera is provided by the self-switching power supply.
Large Format PIXIS: 100-240 V
AC
; 50/60 Hz, 2A. DC power to camera
is provided by the self-switching power supply.
Tripod Mount: 1/4-20 x .25" mounting hole at bottom of camera. M6 threaded adapter
supplied with system.
A/D Converters: Dual digitizers with 100 kHz/2 MHz readout rates. Software-
selectable. Low-speed operation gives better noise performance; high-speed
operation allows faster data acquisition.
