8—SPARE PARTS
8.2 - SPARE PARTS OVENS BASIC XL
DESCRIPTION
BASIC
XL 3L
BASIC
XL 33L
BASIC
XL 4
BASIC
XL 44
BASIC
XL 6
BASIC
XL 66
1/A Door Handle
7M010007 7M010007 7M010005 7M010005 7M010005 7M010005
1/B Small lateral door handles
5M200016 5M200016 5M200016 5M200016 5M200016 5M200016
2/A Door supporting plate (right)
4P100007 4P100007 4P100007 4P100007 4P100007 4P100007
2/B Door supporting plate (left)
3 Washer
3R030001 3R030001 3R030001 3R030001 3R030001 3R030001
4 Door
4P050018 4P050018 4P050017 4P050017 4P050017 4P050017
5 Door Glass
5V010015 5V010015 5V010015 5V010015 5V010015 5V010015
6 Door glass gasket
5G100001 5G100001 5G100001 5G100001 5G100001 5G100001
7 Counterdoor
4C020028 4C020028 4C020027 4C020027 4C020027 4C020027
8 Door Frame
4T020005 4T020005 4T020026 4T020026 4T020026 4T020026
9 Plate fixing screws
5V500019 5V500019 5V500019 5V500019 5V500019 5V500019
10 Frontage
4F020023 4F020028 4F020022 4F020027 4F020022 4F020027
11/A Control panel frame
4M020002 4M020002 4M020001 4M020001 4M020001 4M020001
11/B Control panel label
5E200401 5E200401 5E200400 5E200400 5E200400 5E200400
12 Insulating material
5L010001 5L010001 5L010001 5L010001 5L010001 5L010001
13 Left covering panel
4P040041 4P040043 4P040007 4P040017 4P040027 4P040037
14 Top covering panel
4C030015 4C030015 4C030007 4C030007 4C030009 4C030009
15 Back covering panel
4S030229 4S030230 4S030202 4S030207 4S030202 4S030207
16 Right covering panel
4P040040 4P040042 4P040003 4P040012 4P040022 4P040032
17 Bottom covering pannel
4B030013 4B030013 4B030002 4B030002 4B030009 4B030009
18 Jacket
4I020002 4I020004 4I020003 4I020012 4I020007 4I020017
19 Cooking chamber
7C010108 7C010108 7C010103 7C010103 7C010107 7C010107
20 Chimney
4C030001 4C030005 4C030001 4C030005 4C030001 4C030005
24
Heating elements supporting
frame
4T060080 4T060080 4T060065 4T060065 4T060070 4T060070
25 Lamp holder
5P110003 5P110003 5P110003 5P110003 5P110003 5P110003
26 Lamp glass
5V010003 5V010003 5V010003 5V010003 5V010003 5V010003
27 Lamp
5L020005 5L020005 5L020005 5L020005 5L020005 5L020005
29 Circuit brakers board
- - - - 5S010050 5S010050
30 Thermostat
5T010001 5T010001 5T010001 5T010001 5T010001 5T010001
31 Thermostat knob
5M200003 5M200003 5M200003 5M200003 5M200003 5M200003
34 Thermometer
5T010200 5T010200 5T010200 5T010200 5T010200 5T010200
35
Heating element's warning
light
5L020017 5L020017 5L020017 5L020017 5L020017 5L020017
36 Heating element's switch
5I100016 5I100016 5I100016 5I100016 5I100016 5I100016
37 Chamber light switch
5I100017 5I100017 5I100017 5I100017 5I100017 5I100017
38 Heating element
5R050420 5R050420 5R050400 5R050400 5R050410 5R050410
39 Refractory stone
5P050050 5P050050 5P050040 5P050040 5P050050 5P050050
41 Terminal box
5M100010 5M100010 5M100010 5M100010 5M100010 5M100010
