12/44
* When using a SD card with GP-4301T, please verify it supports the following
specifications:
For the GP-PRO/PBIII’s “CF Card output folder” setting, if project file is converted
on GP-Pro EX, the setting will automatically change to the one that uses a SD card.
To change the setting of the output destination folder, see [5.1 Changing the
setting of the external media to use].
2.6 Peripheral units and option units
2.6.1 1 Barcode reader connection
GP-4501T/TW is not equipped with a tool port. A barcode reader that used to be
connected to the tool port on GP-577RT/S cannot be used. However, GP-4501T/TW
allows you to connect a barcode reader on its USB interface (Type A) or its serial
interface.
For the models GP-4501T/TW supports, see [OtasukePro!]
(http://www.pro-face.com/otasuke/qa/3000/0056_connect_e.html).
2.6.2 Printer connection
(only when using GP-377R and “Multi-Unit E” (GP377R-MLTE11))
GP4000 series is not equipped with Centronics (parallel) Interface for a printer
though Multi-unit E (GP377R-MLTE11) is equipped with it. If the printer for GP-377R
is used for GP4000 series, a converter that converts USB I/Fon GP4000 series to
Centronics I/F is required. And GP4000 series allows you to connect a printer on its
USB port.
For the models GP4000 series supports, see [OtasukePro!]
(http://www.pro-face.com/otasuke/qa/3000/0056_connect_e.html).
2.6.3 Expansion Unit
GP4000 series is not equipped with an expansion unit interface. The expansion unit
(each kind of unit like CC-LINK Unit) for GP-377R/377S/377L cannot be used.
2.6.4 Front Maintenance Unit
The front maintenance unit for GP-377R (GP077-CFFM10) cannot be used for
GP4000 series.
2.6.5 Isolation Unit
The isolation unit for GP-377R/377S/377L (CA2-ISOALL232-01,
CA2-ISOALL422-01) cannot be used for GP4000 series. You can use the RS-232C
isolation unit for GP4000 series (CA3-ISO232-01) instead.
To Next Page
