Pro-face GP-4301T Replacement Guidebook

13/44
2.7 Power Connector
The power connector on GP4000 series (DC type) is a spring lock type. If you
GP-377R/377S/377L with GP4000 series (DC type), change the power cable.
2.8 Backup Battery (Only GP-4301T)
Unlike GP-377R/377S/377L, GP-4301T does not use rechargeable secondary batteries
but replaceable primary ones. (For both a rechargeable type and a replaceable one,
contents to be backed up are the same.)
When the time for replacement of backup batteries approaches, the message to urge
you to replace the battery, “RAAA053: Running out of power in the backup battery.
Please change the battery.” appears. When the message appears, replace the battery
referring to the GP4000 series hardware manual.
Replaceable Battery Model
PFXZCBBT1
2.9 Power Consumption
The power consumption of GP-577RT/S is different from that of GP-4501T/TW.
DC Type
GP-377R/377S/377L
20W or less
GP-4301T/ GP-4301TW
10.5W or less
For the detailed electric specifications, see the hardware manual.
2.10 About Pro-Server
If the Pro-Server with Pro-Studio is used for 377R, please use the Pro-Server EX
Ver.1.30 or later. For details of the installation, refer to the
http://www.pro-face.com/otasuke/qa/server_ex/replace/.
2.11 Other Notes
 Do not expose GP4000 series to direct sunlight.
 Do not use GP4000 series outdoors.
 Do not turn on GP4000 series if condensation has occurred inside the device.
 When you are continuously using GP4000 series without oxygen, the brightness might
decrease. Please ventilate the control panel periodically.
