Pro-face GP-4503T User Manual

GP4000 Series Hardware Manual
167
Periodic Check Points
Operation Environment
z Is the operating temperature within the allowable range? Refer to Environmental
Specifications (see page 46), (see page 66), (see page 84), (see page 99),
(see page 119).
z Is the operating humidity within the specified range? (10%RH to 90%RH, dry bulb
temperature of 39 °C [102.2 °F] or less)
z Is the operating atmosphere free of corrosive gasses?
When the GP unit is inside a panel, the ambient environment refers to the interior of
the panel.
Electrical Specifications
Is the input voltage appropriate?
z 100 Vac to 240 Vac 50/60 Hz
z 19.2 Vdc to 28.8 Vdc
Related Items
z Are all power cords and cables connected properly? Are there any loose cables?
z Are all mounting brackets holding the unit securely?
z Are there scratches or traces of dirt on the installation gasket?

Pro-face GP-4503T Specifications

General

Display Type	TFT Color LCD
Touch Type	Analog Resistive
Power Supply	24 VDC
Backlight	LED
Touch Panel Resolution	1024 x 1024
SD Card Slot	Yes
Display Size	10.4 inches
Resolution	800 x 600 pixels
Operating Temperature	0 to 50 °C
Communication Ports	RS-232, RS-422, RS-485
Colors	65, 536 colors
Ethernet	10/100BASE-T
USB	USB 2.0
Storage Temperature	-20 to 60 °C
Relative Humidity	10% to 90% (non-condensing)
Weight	3.5 kg
Serial Interface	RS-232C, RS-422/485
